Description
Makita GAG03Z Description
The 40V max XGT® Brushless Cordless 4-1/2" / 5” Paddle Switch Angle Grinder with Electric Brake (GAG03Z, tool only) delivers corded grinding performance without the cord for the most demanding applications. It's powered by a Makita-built brushless motor which delivers 8,500 RPM for heavy-load applications and increased power and speed. The GAG03Z offers up to 60% faster cutting speed when cutting #5 (5/8”) rebar. It is ideal for grinding and cutting a wide range of materials including tile, concrete, pipe, conduit, and more. An electric current limiter helps protect the motor from overload in high-torque applications. Makita’s exclusive Automatic Speed Change™ technology automatically adjusts speed and torque during operation for optimal performance. Additional features include an electric brake that stops the grinding or cut-off wheel in 2 seconds or less and Active Feedback-sensing Technology (AFT®) that turns the motor off if rotation of the wheel is forced to a stop. A large paddle switch provides power-start press points at multiple grip positions. A quick guard rotation provides tool-less adjustments for increased productivity. Anti-restart protection is engineered to prevent motor start-up when the battery is inserted while the switch is locked on. A soft start suppresses start-up reaction and provides smooth start-ups. Wire mesh intake covers are engineered to prevent debris from entering the motor. The GAG03Z is also equipped with Makita's Extreme Protection Technology (XPT™), a series of protective seals inside the tool. XPT is designed to improve a tool’s operation in harsh conditions by channeling water and dust from key internal components. Reinforced metal gear housing provides additional durability on the job site. XGT is a system of equipment, tools, batteries and chargers utilizing 40v max lithium-ion batteries. XGT is engineered to deliver high power to take on high-demand applications, allowing users to completely transition to a cordless job site. XGT is equipped with advanced brushless motor engineering, intelligent digital communication, and superior durability features to outpower, outsmart and outlast the competition.
Makita GAG03Z Includes
- 5" x 1/4" x 7/8" INOX Grinding Wheel, 36 Grit (A-95962)
- 5" Tool-Less Wheel Guard (140N43-5)
- Lock Nut Wrench (782424-9)
- Side Handle
Makita GAG03Z Features
- OUTPOWER: Makita-built brushless motor along with 40V max XGT® battery combine to deliver powerful grinding and up to 60% faster cutting speed than predecessor models*
- OUTSMART: Electric brake stops the grinding or cut-off wheel in 2 seconds or less for maximum productivity
- OUTLAST: Electronic current limiter helps protect the motor from overload in high torque application
- Active Feedback-sensing Technology (AFT®) turns the motor off if rotation of the wheel is suddenly forced to stop
- Anti-restart protection engineered to prevent motor start up when battery is inserted with switch locked on
- Large paddle switch allows for power start press points at multiple grip positions
- Quick guard rotation allows easy tool-less adjustment for increased productivity
- Soft start suppresses start-up reaction for smooth start-ups and longer gear life
- Spiral bevel gears for smoother rotations and a more efficient transfer of energy
- Reinforced metal gear housing engineered for maximum job site durability
- Wire mesh intake covers are engineered to prevent debris from entering motor
- Extreme Protection Technology (XPT™) is engineered for improved dust and water resistance for operation in harsh conditions
- Rubberized soft grip provides increased comfort on the job
- Compact at only 16-1/8" long; ideal for tight spaces
- The digital communication within XGT® optimizes performance to provide up to 2X longer sustained power under heavy-load applications
- The digital communication within XGT® actively monitors and protects against overload, over-discharge and overheating
- XGT® Tools and Batteries are designed with a multi-layer contact interface for more constant power delivery to take on high-current demands
- XGT® Batteries feature rigid rails with impact-resistant construction to secure the battery to the tool during high-demand applications (batteries not included)
Makita GAG03Z Specifications
System | XGT |
Wheel Diameter | 5" |
No Load Speed | 8,500 RPM |
Spindle Type | 5/8" - 11 UNC |
Lock-On Switch | Yes |
Lock-Off Switch | No |
Switch Type | Body grip/paddle |
Bind-Up Control | Yes |
Electric Brake | Yes |
Variable speed dial | No |
Automatic-start Wireless System (AWS™) | No |
Overall Length | 16-1/8" |
Net Weight (with battery) | 7.9 lbs. |
Power Type | Cordless |
Shipping Weight | 7.56 lbs. |
UPC Code | 088381-898515 |
