Description
INCLUDES:
• Extended Depth Adjustment Knob (158980-5)
• 1/4" Collet (763803-0)
• 1/2" Collet (763622-4)
• Wrench (781030-7)
FEATURES:
• Powerful 15.0 AMP motor delivers 9,000-22,000 RPM for smooth routing
• 0" - 2-3/4" plunge depth capacity for easy penetration into work piece
• Electronic speed control maintains constant speed under load
• Variable speed control dial enables user to match the speed to the application
• Soft start feature for smooth start-ups
• Electric brake for increased productivity
• Linear ball bearings for smooth plunge action and superior performance
• Quick release plunge depth adjustment with micro control along with 3 preset depth stops for added precision
• Built-in twin L.E.D. lights illuminate the work area for increased visibility
• Oversized ball bearing construction for longer tool life
• Ergonomic rubberized handles with built-in large two-finger switch for added control and use
• Conveniently located plunge lock lever for efficient operation
• Shaft lock for quick and easy bit changes
• "Tool-less" template guide system for quick and easy installation and removal
• Lock-on trigger switch for continuous operation
• Built in fan with labyrinth construction minimizes dust from entering the tool for longer tool life
• Easy-to-read depth scales
• Chip deflector engineered to direct chips away from the operator
SPECIFICATIONS:
• Collet Capacity 1/4" & 1/2"
• Plunge Capacity 0"-2-3/4"
• No Load Speed 9,000-22,000 RPM
• AMPS (120V) 15.0
• Max Horsepower* 3-1/4
• Overall Height 12-1/4"
• Extended Depth Adjustment Knob (158980-5)
• 1/4" Collet (763803-0)
• 1/2" Collet (763622-4)
• Wrench (781030-7)
FEATURES:
• Powerful 15.0 AMP motor delivers 9,000-22,000 RPM for smooth routing
• 0" - 2-3/4" plunge depth capacity for easy penetration into work piece
• Electronic speed control maintains constant speed under load
• Variable speed control dial enables user to match the speed to the application
• Soft start feature for smooth start-ups
• Electric brake for increased productivity
• Linear ball bearings for smooth plunge action and superior performance
• Quick release plunge depth adjustment with micro control along with 3 preset depth stops for added precision
• Built-in twin L.E.D. lights illuminate the work area for increased visibility
• Oversized ball bearing construction for longer tool life
• Ergonomic rubberized handles with built-in large two-finger switch for added control and use
• Conveniently located plunge lock lever for efficient operation
• Shaft lock for quick and easy bit changes
• "Tool-less" template guide system for quick and easy installation and removal
• Lock-on trigger switch for continuous operation
• Built in fan with labyrinth construction minimizes dust from entering the tool for longer tool life
• Easy-to-read depth scales
• Chip deflector engineered to direct chips away from the operator
SPECIFICATIONS:
• Collet Capacity 1/4" & 1/2"
• Plunge Capacity 0"-2-3/4"
• No Load Speed 9,000-22,000 RPM
• AMPS (120V) 15.0
• Max Horsepower* 3-1/4
• Overall Height 12-1/4"
